Nominal pressure difference (between main in/out lines): 120 kPa
Maximum pressure difference (between main in/out lines): 200 kPa
￭ Cooling circuit materials
Materials used in the internal cooling circuit are listed below. These are also the only materials
that can be used in the external cooling circuit.
• stainless steel AISI 316L (UNS 31603)
• heavy gauge aluminum
• plastic materials such as PA, PEX and PTFE
Note: PVC hoses are not suitable for use with antifreeze.
• rubber gasketing NBR (nitrile rubber).
WARNING!
If connecting external piping to the internal cooling circuit, use only materials
that are specified above. Copper, brass or bronze must not be used under
any circumstances. Even minor dissolution of copper can cause copper
precipitation on aluminum and subsequent galvanic corrosion. The liquid
cooling system must not contain any zinc (eg. galvanized pipes).
If the plant incorporates normal iron pipes or cast iron accessories (eg. motor housings), a
cooling unit with a heat exchanger (such as the ACS880-1007LC) must be used to separate
the systems.
Internal cooling circuit 149
