ABB ACS880-07CLC

Output cable sizes
This table gives typical cable sizes for:
• Marine-type cable with copper conductors such as Nexans MPRXCX
®
FLEXISHIP
®
EMC 0.6/1 (1.2) kV
• Industrial-type aluminum and copper cable types. The cable sizing is based on max. 9
cables laid on the cable trays side by side, three ladder type trays one on top of the
other, ambient temperature 30 °C (EN 60204-1 and IEC 60364-5-52). A correction factor
K = 0.70 is used.
Industrial-type cableMarine-type cable
ACS880-07CLC-…
Copper with PVC insula-
tion
Aluminum with PVC insula-
tion
Copper
mm
2
mm
2
mm
2
U
N
= 690 V, 6-pulse connection
2 × (3 × 150 + 70)2 × (3 × 185 + 57 Cu)3 × (3 × 95)0390A-7
2 × (3 × 150 + 70)2 × (3 × 240 + 72 Cu)3 × (3 × 95)0430A-7
2 × (3 × 185 + 95)3 × (3 × 150 + 41 Cu)3 × (3 × 95)0480A-7
2 × (3 × 240 + 120)3 × (3 × 185 + 57 Cu)4 × (3 × 95)0530A-7
2 × (3 × 240 + 120)3 × (3 × 240 + 72 Cu)4 × (3 × 95)0600A-7
3 × (3 × 185 + 95)3 × (3 × 240 + 72 Cu)4 × (3 × 120)0670A-7
3 × (3 × 185 + 95)4 × (3 × 185 + 57 Cu)4 × (3 × 120)0750A-7
4 × (3 × 150 + 70)4 × (3 × 240 + 72 Cu)4 × (3 × 120)0850A-7
2 × 2 × (3 × 240 + 120)2 × 3 × (3 × 185 + 57 Cu)2 × 4 × (3 × 95)1030A-7
2 × 2 × (3 × 240 + 120)2 × 3 × (3 × 185 + 57 Cu)2 × 4 × (3 × 95)1170A-7
2 × 3 × (3 × 150 + 70)2 × 4 × (3 × 150 + 41 Cu)2 × 4 × (3 × 95)1310A-7
2 × 3 × (3 × 185 + 95)2 × 4 × (3 × 185 + 57 Cu)2 × 4 × (3 × 120)1470A-7
2 × 3 × (3 × 240 + 120)2 × 4 × (3 × 240 + 72 Cu)2 × 4 × (3 × 120)1660A-7
3 × 3 × (3 × 150 + 70)3 × 3 × (3 × 240 + 72 Cu)3 × 4 × (3 × 95)1940A-7
3 × 3 × (3 × 185 + 95)3 × 4 × (3 × 185 + 57 Cu)3 × 4 × (3 × 120)2180A-7
3 × 3 × (3 × 240 + 120)3 × 4 × (3 × 240 + 72 Cu)3 × 4 × (3 × 150)2470A-7
4 × 3 × (3 × 185 + 95)4 × 4 × (3 × 185 + 57 Cu)4 × 4 × (3 × 120)2880A-7
4 × 3 × (3 × 240 + 120)4 × 4 × (3 × 240 + 72 Cu)4 × 4 × (3 × 150)3260A-7
U
N
= 690 V, 12-pulse connection
2 × (3 × 240 + 120)3 × (3 × 185 + 57 Cu)4 × (3 × 95)0530A-7+A004
2 × (3 × 240 + 120)3 × (3 × 240 + 72 Cu)4 × (3 × 95)0600A-7+A004
3 × (3 × 185 + 95)3 × (3 × 240 + 72 Cu)4 × (3 × 120)0670A-7+A004
3 × (3 × 185 + 95)4 × (3 × 185 + 57 Cu)4 × (3 × 120)0750A-7+A004
4 × (3 × 150 + 70)4 × (3 × 240 + 72 Cu)4 × (3 × 120)0850A-7+A004
2 × 2 × (3 × 240 + 120)2 × 3 × (3 × 185 + 57 Cu)2 × 4 × (3 × 95)1030A-7+A004
2 × 2 × (3 × 240 + 120)2 × 3 × (3 × 185 + 57 Cu)2 × 4 × (3 × 95)1170A-7+A004
2 × 3 × (3 × 150 + 70)2 × 4 × (3 × 150 + 41 Cu)2 × 4 × (3 × 95)1310A-7+A004
2 × 3 × (3 × 185 + 95)2 × 4 × (3 × 185 + 57 Cu)2 × 4 × (3 × 120)1470A-7+A004
2 × 3 × (3 × 240 + 120)2 × 4 × (3 × 240 + 72 Cu)2 × 4 × (3 × 120)1660A-7+A004
3 × 3 × (3 × 150 + 70)3 × 3 × (3 × 240 + 72 Cu)3 × 4 × (3 × 95)1940A-7+A004
Technical data 163
