Terms and abbreviations
DescriptionTerm/
Abbreviation
Type of control unitBCU
Frequency converter for controlling AC motorsDrive
Electromagnetic compatibilityEMC
Electromagnetic interferenceEMI
Optional TTL incremental encoder interface moduleFEN-01
Optional TTL absolute encoder interface moduleFEN-11
Optional resolver interface moduleFEN-21
Optional HTL incremental encoder interface moduleFEN-31
Optional analog I/O extension moduleFIO-11
Optional thermistor protection moduleFPTC-01
Optional ATEX-certified thermistor protection module for potentially explosive atmospheresFPTC-02
Physical size of the drive or power moduleFrame, frame
size
Functional safety modules (not available for the ACS880-07CLC at the time of publishing)FSO-12, FSO-
21
Insulated gate bipolar transistorIGBT
Inverter module(s) under control of one control board, and related components. One inverter
unit typically controls one motor.
Inverter unit
Common term for drive module, inverter module, supply module, brake chopper module etc.Power module
Radio-frequency interferenceRFI
Safe torque off (IEC/EN 61800-5-2)STO
Supply module(s) under control of one control board, and related components.Supply unit
Related manuals
CodeName
Drive hardware manuals and guides
3AXD50000131457ACS880-07CLC drives hardware manual
3AUA0000085685ACX-AP-x assistant control panels user’s manual
Drive firmware manuals and guides
3AUA0000085967ACS880 primary control program firmware manual
3AUA0000098062Quick start-up guide for ACS880 drives with primary control program
3AUA0000103295ACS880 diode supply control program firmware manual
3AXD50000126880ACS880 distributed I/O bus supplement
Option manuals and guides
3AXD50000129607ACS880-1007LC liquid cooling unit user's manual
3AUA0000094606Drive composer start-up and maintenance PC tool user’s manual
3AXD50000123384User’s manual for Emergency stop, stop category 0 (+Q951) for ACS880-07CLC drives
3AXD50000207848User’s manual for Emergency stop, stop category 0 (+Q951+Q984) for ACS880-07CLC
drives
Manuals and quick guides for I/O extension modules, fieldbus adapters, etc.
