ABB ACS880-07CLC

Dimensions
Cabinet line-up dimensions
The drive consists of cubicles built into a cabinet line-up. The table below shows the width
and weight of basic drive types without options (for example, the cooling unit is not included).
The table is followed by selected dimension drawing examples.
The dimensions are in millimeters (for inches, divide by 25.4).
The data given is preliminary. ABB reserves the right to modify the design at any time without
notice. Consult ABB for up-to-date, drive-specific information.
WeightWidth
ACS880-07CLC-…
lbskgmm
U
N
= 690 V, 6-pulse connection
12355607300390A-7
12355607300430A-7
12355607300480A-7
12355607300530A-7
12355607300600A-7
12355607300670A-7
12355607300750A-7
12355607300850A-7
15657109301030A-7
15657109301170A-7
15657109301310A-7
15657109301470A-7
15657109301660A-7
2270103012301940A-7
