ABB ACS880-07CLC

E
R
Duty cycle
(10/60 s)
Duty cycle
(1/5 min)
P
brcont
I
rms
I
max
R
min
P
brmax
Resistor type
Module
type
ACS880-
607LC-…
I
rms
P
br
I
rms
P
br
kJAkWAkWkWAAohmkW
6480015421724894100032458250101.3524226 × (2 ×
SAFUR200F500)
6 ×
NBRW-
669C
2400-7
￭ Definitions
Nominal voltage
U
N
Nominal (recommended) resistance of the resistor assembly of one chopper module
R
n
Resistance of specified resistors (per chopper module). This is also the minimum allowed resistance
for the resistor assembly.
R
min
Maximum short-term (1 min in every 10 min) braking power
P
brmax
Maximum continuous power rating
P
brcont
Maximum peak current
I
max
Maximum braking power for the specified duty cycle
P
br
Rms current for the specified duty cycle
I
rms
￭ SAFUR resistor data
The following SAFUR resistors are available separately.
IPxx
P
Rcont
E
R
RU
N
Type
kWkJohmV
IP009.036004.0500SAFUR125F500
IP0010.542003.4575SAFUR210F575
IP0013.554002.7500SAFUR200F500
IP0015.060002.4460SAFUR180F460
Nominal voltage
U
N
Resistance
R
Short energy pulse that the resistor assembly will withstand each 400 seconds
E
R
Continuous power (heat) dissipation of the resistor when placed correctly. Energy E
R
dissipates in
400 seconds.
P
Rcont
Degree of protectionIPxx
￭ Terminals and cable lead-through data of factory-installed
chopper/resistor cubicles
See the dimension drawings delivered with the unit.
Resistor braking 205
