2. An EMC plan for preventing disturbances is drawn up for the installation. A template is
available from the local ABB representative.
3. The input power cables, motor cables and control cables are selected as specified in
the appropriate drive manual(s).
4. The drive is installed according to the instructions given in the appropriate drive
manual(s).
WARNING!
A drive of category C4 is not intended to be used on a low-voltage public network
which supplies domestic premises. Radio frequency interference is expected if
the drive is used on such a network.
Tightening torques
Unless a tightening torque is specified in the text, the following torques can be used.
￭ Electrical connections
NoteTorqueSize
Strength class 4.6...8.80.5 N·m (4.4 lbf·in)M3
Strength class 4.6...8.81 N·m (9 lbf·in)M4
Strength class 8.84 N·m (35 lbf·in)M5
Strength class 8.89 N·m (6.6 lbf·ft)M6
Strength class 8.822 N·m (16 lbf·ft)M8
Strength class 8.842 N·m (31 lbf·ft)M10
Strength class 8.870 N·m (52 lbf·ft)M12
Strength class 8.8120 N·m (90 lbf·ft)M16
￭ Mechanical connections
NoteMax. torqueSize
Strength class 8.86 N·m (53 lbf·in)M5
Strength class 8.810 N·m (7.4 lbf·ft)M6
Strength class 8.824 N·m (17.7 lbf·ft)M8
￭ Insulation supports
NoteMax. torqueSize
Strength class 8.85 N·m (44 lbf·in)M6
Strength class 8.89 N·m (6.6 lbf·ft)M8
Strength class 8.818 N·m (13.3 lbf·ft)M10
