ABB ACS880-07CLC

Industrial-type cableMarine-type cable
ACS880-07CLC-…
Copper with PVC insula-
tion
Aluminum with PVC insula-
tion
Copper
mm
2
mm
2
mm
2
3 × 3 × (3 × 185 + 95)3 × 4 × (3 × 185 + 57 Cu)3 × 4 × (3 × 120)2180A-7+A004
3 × 3 × (3 × 240 + 120)3 × 4 × (3 × 240 + 72 Cu)3 × 4 × (3 × 150)2470A-7+A004
4 × 3 × (3 × 185 + 95)4 × 4 × (3 × 185 + 57 Cu)4 × 4 × (3 × 120)2880A-7+A004
4 × 3 × (3 × 240 + 120)4 × 4 × (3 × 240 + 72 Cu)4 × 4 × (3 × 150)3260A-7+A004
5 × 3 × (3 × 185 + 95)5 × 4 × (3 × 185 + 57 Cu)5 × 4 × (3 × 120)3580A-7+A004
5 × 3 × (3 × 240 + 120)5 × 4 × (3 × 240 + 72 Cu)5 × 4 × (3 × 150)4050A-7+A004
6 × 4 × (3 × 150 + 70)6 × 4 × (3 × 240 + 72 Cu)6 × 4 × (3 × 150)4840A-7+A004
7 × 3 × (3 × 240 + 120)7 × 4 × (3 × 240 + 72 Cu)7 × 4 × (3 × 150)5650A-7+A004
8 × 4 × (3 × 185 + 95)8 × 4 × (3 × 240 + 72 Cu)8 × 4 × (3 × 150)6460A-7+A004
U
N
= 690 V, 24-pulse connection
3 × 3 × (3 × 240 + 120)3 × 4 × (3 × 240 + 72 Cu)3 × 4 × (3 × 150)2470A-7+A006
4 × 3 × (3 × 240 + 120)4 × 4 × (3 × 240 + 72 Cu)4 × 4 × (3 × 150)3260A-7+A006
6 × 4 × (3 × 150 + 70)6 × 4 × (3 × 240 + 72 Cu)6 × 4 × (3 × 150)4840A-7+A006
7 × 3 × (3 × 240 + 120)7 × 4 × (3 × 240 + 72 Cu)7 × 4 × (3 × 150)5650A-7+A006
8 × 4 × (3 × 185 + 95)8 × 4 × (3 × 240 + 72 Cu)8 × 4 × (3 × 150)6460A-7+A006
Terminal and lead-through data for the power cables
The locations and sizes of lead-throughs are shown by the dimension drawings delivered
with the drive, and the dimension drawing examples in this manual.
Terminal data for the supply and inverter control units
See chapter Control units of the drive (page 103).
Contact data for main contactor/breaker control
￭ General
The main contactor or breaker is controlled by the drive through relay K3. The relay has
one normally-open (NO) and one normally-closed (NC) contact.
Emergency stop options add a relay (K640) to the drive. To trip the main breaker upon an
emergency stop, one of the output switchover contacts of K640 must be wired to the
undervoltage coil.
The contacts of both relays are wired to a terminal block in the drive cubicle; see the
drive-specific circuit diagrams for details. The external voltage switched by the contacts is
to be connected to the same terminal block.
￭ K3 contact data
•
Rated operational AC current (I
e
) (IEC/EN 60947-5-1 AC 15):
• 24…127 V, 50/60 Hz: 6 A
• 220…240 V, 50/60 Hz: 4 A
• 400…440 V, 50/60 Hz: 3 A
164 Technical data
