ABB ACSM1 User Manual

List of related manuals
*
)
A multilingual quick installation guide is included with the delivery.
You can find manuals and other product documents in PDF format on the Internet. See section
Document library on the Internet on the inside of the back cover. For manuals not available in the
Document library, contact your local ABB representative.
Drive hardware manuals *
)
Code (English)
ACSM1-04 Drive Modules (0.75 to 45 kW) Hardware
Manual
3AFE68797543
ACSM1-04 Drive Modules (55 to 110 kW) Hardware
Manual
3AFE68912130
ACSM1-04Lx Liquid-cooled Drive Modules (55 to 160 kW)
Hardware Manual
3AUA0000022083
Drive firmware manuals
ACSM1 Speed and Torque Control Program Firmware
Manual
3AFE68848261
ACSM1 Motion Control Program Firmware Manual 3AFE68848270
Drive PC tools manuals
DriveStudio User Manual 3AFE68749026
DriveSPC User Manual 3AFE68836590
Application guides
Application guide - Safe torque off function for ACSM1,
ACS850 and ACQ810 drives
3AFE68929814
Functional Safety Solutions with ACSM1 Drives
Application Guide
3AUA0000031517
System Engineering Manual 3AFE68978297
Option manuals *
)
FIO-01 Digital I/O Extension User’s Manual 3AFE68784921
FIO-11 Analog I/O Extension User’s Manual 3AFE68784930
FEN-01 TTL Encoder Interface User’s Manual 3AFE68784603
FEN-11 Absolute Encoder Interface User’s Manual 3AFE68784841
FEN-21 Resolver Interface User’s Manual 3AFE68784859
ACSM1 Control Panel User’s Guide 3AUA0000020131

ABB ACSM1 Specifications

General

Protection Class	IP20
Voltage Range	380 V to 480 V
Product Type Designation	ACSM1
Input Voltage	380-480 V AC
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overload, overtemperature
Operating Temperature	-10°C to +40°C
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m
