ABB ACSM1 User Manual

Parameters and firmware blocks
105
Group 06 DRIVE STATUS
06
6.01 STATUS WORD 1 FW block: DRIVE LOGIC (page 120)
Status word 1.
Bit Name Val. Information
0 READY 1 Drive is ready to receive start command.
0 Drive is not ready.
1 ENABLED 1 External run enable signal is received.
0 No external run enable signal is received.
2 STARTED 1 Drive has received start command.
0 Drive has not received start command.
3 RUNNING 1 Drive is modulating.
0 Drive is not modulating.
4 EM OFF (OFF2) 1 Emergency OFF2 is active.
0 Emergency OFF2 is inactive.
5EM STOP
(OFF3)
1 Emergency stop OFF3 (ramp stop) is active.
0 Emergency OFF3 is inactive.
6 ACK STARTINH 1 Start inhibit is active.
0 Start inhibit is inactive.
7 ALARM 1 An alarm is active. See chapter Fault tracing.
0 No alarm
8 EXT2 ACT 1 External control EXT2 is active.
0 External control EXT1 is active.
9 LOCAL FB 1 Fieldbus local control is active.
0 Fieldbus local control is inactive.
10 FAULT 1 A fault is active. See chapter Fault tracing.
0 No fault
11 LOCAL PANEL 1 Local control is active, ie, drive is controlled from PC tool or con-
trol panel.
0 Local control is inactive.
12 NOT FAULTED 1 No fault
0 A fault is active. See chapter Fault tracing.
13…15 Reserved

ABB ACSM1 Specifications

General

Protection Class	IP20
Voltage Range	380 V to 480 V
Product Type Designation	ACSM1
Input Voltage	380-480 V AC
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overload, overtemperature
Operating Temperature	-10°C to +40°C
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m
