Parameter data
281
Parameter data
What this chapter contains
This chapter lists the parameters of the drive with some additional data. For the
parameter descriptions, see chapter Parameters and firmware blocks.
Terms
Term Definition
Actual signal Signal measured or calculated by the drive. Can be monitored by the user.
No user setting is possible.
Def Default value
enum Enumerated list, ie, selection list
FbEq Fieldbus equivalent: The scaling between the value shown on the panel
and the integer used in serial communication.
Page no. Page number for more information
INT32 32-bit integer value (31 bits + sign)
Bit pointer Bit pointer. A bit pointer points to a single bit in the value of another
parameter.
Val pointer Value pointer. A value pointer points to the value of another parameter.
Parameter An operation instruction of the drive that is often user-adjustable.
Parameters that are signals measured or calculated by the drive are called
actual signals.
Pb Packed boolean
PT Parameter protection type. See WP, WPD and WP0.
REAL
REAL24
Save PF Parameter setting is protected against power failure.
Type Data type. See enum, INT32, Bit pointer, Val pointer, Pb, REAL, REAL24,
UINT32.
UINT32 32-bit unsigned integer value
WP Write protected parameter (ie, read only)
WPD Write protected parameter while drive is running
WP0 Parameter can only be set to zero.
16-bit value 16-bit value (31 bits + sign)
= integer value = fractional value
8-bit value 24-bit value (31 bits + sign)
= integer value
= fractional value

ABB ACSM1 Specifications

General

Protection Class	IP20
Voltage Range	380 V to 480 V
Product Type Designation	ACSM1
Input Voltage	380-480 V AC
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overload, overtemperature
Operating Temperature	-10°C to +40°C
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m
