Parameters and firmware blocks
140
Group 16 SYSTEM
Local control and parameter access settings, restoration of default parameter
values, save of parameters into permanent memory.
16
16.01 LOCAL LOCK FW block: None
Selects the source for disabling local control (Take/Release button on the PC tool, LOC/REM key of
the panel). 1 = Local control disabled. 0 = Local control enabled.
WARNING! Before activating, ensure that the control panel is not needed for stopping the
drive!
Bit pointer: Group, index and bit
16.02 PARAMETER LOCK FW block: None
Selects the state of the parameter lock. The lock prevents parameter changing.
Note: This parameter can only be adjusted after the correct pass code has been entered at parameter
16.03 PASS CODE.
(0) Locked Locked. Parameter values cannot be changed from the control panel.
(1) Open The lock is open. Parameter values can be changed.
(2) Not saved The lock is open. Parameter values can be changed, but the changes
will not be stored at power switch off.
16.03 PASS CODE FW block: None
After entering 358 at this parameter, parameter 16.02 PARAMETER LOCK can be adjusted.
The value reverts back to 0 automatically.
16.04 PARAM RESTORE FW block: None
Restores the original settings of the application, ie, parameter factory default values.
Note: This parameter cannot be changed while the drive is running.
(0) Done Restoration is completed.
(1) Restore defs All parameter values are restored to default values, except motor
data, motor ID run results, and fieldbus, drive-to-drive link and
encoder configuration data.
(2) Clear all All parameter values are restored to default values, including motor
data, motor ID run results and fieldbus and encoder configuration
data. PC tool communication is interrupted during the restoration.
Drive CPU is re-booted after the restoration is completed.
16.07 PARAM SAVE FW block: None
Saves the valid parameter values to permanent memory.
See also section Programming via parameters on page 30.
(0) Done Save completed.
(1) Save Save in progress.

ABB ACSM1 Specifications

General

Protection Class	IP20
Voltage Range	380 V to 480 V
Product Type Designation	ACSM1
Input Voltage	380-480 V AC
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overload, overtemperature
Operating Temperature	-10°C to +40°C
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m
