Compact MTUs are 58 mm (2.3”) wide and extended MTUs are 120 mm (4.72”) wide. The two
MTU types can be mixed and matched within an I/O-station to fit a user’s needs. Choice of
compact MTU or extended MTU can be made freely trading space versus termination needs.
Compact and extended MTUs are available with rated isolation voltages 50 V and 250 V.
The 50 V types can be used with all 24 V or 48 V discrete I/O and analog I/O modules.
The MTUs with 250 V rated isolation voltage are used with all 120 V and 250 V rated I/O
modules. There is also one compact MTU for modules with Intrinsically safe interface.
7DEOH 60RGXOH7HUPLQDWLRQ8QLWV
0RGXOHW\SH 'HVFULSWLRQ
TU810 Compact MTU, 58 mm wide. Two isolated groups each with
2 rows of 4 uncommitted terminals, 2 pcs L+ terminals and one
row of 5 pcs L-.
Rated isolation voltage 50 V.
Conductor area: 0.2-2.5 mm
2
, AWG 24-12.
TU811 Compact MTU, 58 mm wide. 2 x 8 uncommitted terminals.
Rated isolation voltage 250 V.
Conductor area: 0.2-2.5 mm
2
, AWG 24-12.
TU812 Compact MTU, 58 mm wide. 25 pin D-sub Connector for field
connection
Rated isolation voltage 50 V.
TU814 Compact MTU, 58 mm wide. Crimp Snap-in Connectors for field
connection.
Rated isolation voltage 50 V.
Conductor area: 0.5 - 1.0 mm
2
, AWG 16-22.
TU830 Extended MTU, 120 mm wide. Two isolated groups each with 2
rows of 8 uncommitted terminals, 2 pcs L+ terminals and one row
of 10 pcs L-.
Rated isolation voltage 50V.
Conductor area: 0.2-2.5 mm
2
, AWG 24-12.
TU831 Extended MTU, 120 mm wide. 2 x 8 uncommitted terminals.
Rated isolation voltage 250 V.
Conductor area 0,2-4 mm
2
, AWG 24-10.
TU835 Extended MTU, 120 mm wide. Two isolated groups with 2 rows
each one rows of 4 uncommitted terminals individually fused,
one rows of 4 uncommitted terminals, 2 pcs L+ and 2 pcs
L- terminals.
Rated isolation voltage 50 V.
Conductor area: 0.2-2.5 mm
2
, AWG 24-12.
