ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Section B.5 Protection Rating
3BSE 002 415R701 Rev A B-5
B.5 Protection Rating
Cabinets are available for different environmental protection classes,
see Table B-3.
D3 419 mm (16.5”) 544 mm (21.4”)
Dtot 531 mm (20.9”) 655 mm (25.8”)
Table B-3. RM500 cabinet protection classes
Type
Protection class
RM500
Ventilated, not EMC-proof
(1) (2)
(1) Advant Controller 450 with S100 I/O, installed in this cabinet is not verified for
CE-marking.
(2) Standard cabinet without filter on ventilation grilles.
IP 21
Ventilated, EMC-proof
(2)
IP 21
Ventilated
(3)
(3) Ventilation grilles are covered with metallic net to prevent insects to enter the
cabinet. A heater is included to heat the cabinet when the controller is not in use.
IP 41
Sealed IP 54
Sealed with heat exchanger
(4)
(4) Available as a standard sealed cabinet with heat exchanger as an option.
IP 54
Table B-4. Available Degree of Protection Ratings for RM500
RM500V1
H=1925 mm (75.8 inch.)
RM500V1
H=2125 mm (83.7 inch)
RM500V2
H=2225 mm (87.6 inch.)
IP21 IP41
(1)
(1) IP41 includes a heating element, and the ventilation grilles are covered with nets.
IP54 IP21 IP41
(1)
IP54 IP21 IP41
(1)
IP54
Cabinet with or without
hinged frame
XXXXXXXXX
Cabinet for OOCU X X X X X X
Cabinet, NOT verified
for CE marking
XXX
Table B-2. Distances in Figure B-4
Symbol in
Figure B-4
RM500V1 RM500V2
