ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ$ 5)&RQWUROOHU6 XEUDFN68
3BSE 002 415R701 Rev A A-17
$ 5)&RQWUROOHU6XEUDFN68
• 19-inch standard width
• Height 300 mm (12 SU)
• Futurebus+ back plane.
'HVFULSWLRQ
Subrack for electronic modules with front connection of cables.
Mount the subrack close to the back wall in a cabinet. Admittance
to the rear side of the subrack is not necessary after the installation.
A number of slots for modules of different sizes are included. See figure below.
Each module is individually locked by snap-on handle and screws.
The back plane is raised 35 mm and provides test and connection facilities
for the power supply and battery supply.
A fan unit, RC527, is mounted beneath the subrack. This unit provides a cable
duct to use for the cables connected to the modules.
.
B
l
i
n
d
)URQWYLHZ
X1 X2X3
