ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
$SSHQGL[$ +DUGZDUH0RGXOHV
A-16 3BSE 002 415R701 Rev A
7HFKQLFDO'DWD
3RZHU6XSSO\
24 V d.c., max. 0.7 A (for three fans)
Power loss (heat) typical 15 W
)XVHV
Each fan protected by a 0.8 A F Miniature Fuse Link.
$ODUP,QGLFDWLRQ
FANFAIL-signal Low level/0 V - Fan OK
High level/16.3 - 32 V - One or more fans have failed (<750 rpm)
Loadable <7.3 mA
0HFKDQLFDO'DWD
Dimension: 482 mm x 330 mm x 100 mm (19” x 13” x 4”) excl. cable duct
482 mm x 425 mm x 100 mm (19” x 16.7” x 4”) incl. cable duct
Weight: 3 kg (6.6 lbs.)
0DLQWHQDQFH3DUWV
Miniature Fuse Link, 5 x 20mm, 0.8AF fast, ABB part no. 3BSC 770 001 R43
Filter Carpet (dust filter) ABB part no. 3BSC 930 057 R0001
Fan (spare part) ABB part no. 6480 096-9
%ORFN'LDJUDP
Fan 1
Fan 2
Fan 3
Power Supply
Power Supply
Power Supply
Sensor
Sensor
Sensor
X4
X5
X6
Sensor Supervision
+24VA
+24VB
0V
FANFAIL
Fuses
X2
0V
X3
+24V
X1
0V
Printed Circuit Board
1
2
1
2
1
2
3
0V1
2
0V
0V
3
1
2
3
1
2
