ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-58 3BSE 002 415R701 Rev A
'LJLWDO2XWSXW%ORFN'LDJUDP
$QDORJ,QSXWIRU6WDQGDUG6LJQDO0DLQ3RLQWV
• Input units are available for standard voltage or current signals, single-ended or
differential, with or without live zero.
• An isolation amplifier is available in the form of a connection unit. The isolation
voltage is 3 kV.
• Some board has reference channels for automatic calibration and testing.
• The data base is updated by scanning, with cycle times normally selected from the
range 100 ms to 600 s.
• Optional software filtering, square-root linearization and deadband limits for updating
can be selected.
• Optional redundancy. Two types of boards can be duplicated to achieve increased
availability.
• A board is offered which combines analog inputs and analog outputs (loop dedicated I/O).
$QDORJ,QSXWIRU3W0DLQ3RLQWV
• Different temperature ranges for optimization of measurement accuracy.
• A 13-bit resolution unit is available. This very high resolution requires special precautions
when it comes to cabling. The unit can optionally be used with 12-bit resolution.
DSDO 115A 32 channels, 24 V d.c., short-circuit protected,
transistor output, max. 150 mA
DSTD 110A / DSTD 190V1 DSTK 221L3
DSDO 120A 16 channels, 24/48 V d.c, transistor output,
max. 1 A
DSTD 120A DSTK 220L3,2
(1) DSTD 108L is used for low-current loads (max. 200 mA).
)LJXUH  'LJLWDO2XWSXW6LJQ DO%OR FN'LDJUDP
7DEOH 'LJLWDO2XWSXW%RDUGV
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
Program
&RQWUROOHU
VRIWZDUH
6LJQDODGDSWDWLRQXQLW 3URFHVV
Digital
output board
Connection
unit
Status indication (yellow)
Unit
controlled:
lamp
,
contactor,
etc.
Data base
