ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ 3URFHVV,QWHUIDFH
3BSE 002 415R701 Rev A 1-57
'LJLWDO2XWSXW%RDUG7\SHV
Table 1-14 presents available digital output boards.
7DEOH 'LJLWDO2XWSXW%RDUGV
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
DSDO 115 32 channels, 24 V d.c. 4 x
DSTD 108 / DSTD 108L
(1)
These connection units pro-
vide 8 relay outputs each, 24
- 250 V a.c./ d.c. max 3 A.
DSTK 226L3
DSDO 115A 32 channels, 24 V d.c. 4 x DSTD 108P /
DSTD 108LP
(1)
These connection units pro-
vide 8 relay outputs each, 24
- 250 V a.c./ d.c. max 3 A.
DSTK 226L3
DSDO 115 32 channels, 24 V d.c. Variants below provides
object oriented connection to
DSDI 110A and DSDO 115,
various rated input voltages:
24 V d.c. DSTD 145
120 V a.c. DSTD 147
230 V a.c. DSTD 148
These connection units
include 8 relay outputs each,
24 - 250 V a.c./ d.c. max 3 A.
DSTK 226L5
DSTK 226L5
DSTK 226L5
DSDO 115A 32 channels, 24 V d.c. Variants below provides
object oriented connection to
DSDI 110AV1 and
DSDO 115A, various rated
input voltages:
24 V d.c. DSTD 145
120 V a.c. DSTD 147
230 V a.c. DSTD 148
These connection units
include 8 relay outputs each,
24 - 250 V a.c./ d.c. max 3 A.
DSTK 226L5
DSTK 226L5
DSTK 226L5
DSDO 115 32 channels, 24 V d.c., short-circuit protected,
transistor output, max. 150 mA
DSTD 110A / DSTD 190 DSTK 221L3
