Advant
®
Controller 450 User’s Guide
Section 5.5.11 Adjustment of Analog Input and Output Boards
3BSE 002 415R701 Rev A 5-75
Adjustment Possibilities on Circuit Boards
Table 5-3 shows the adjustments possible on the various analog input and output boards.
Key to the signs:
Z - Zero, G - Gain, B - Balance, S - Symmetry, V - Variable gain, L1/L2 - Limits
5.5.11.1 Channel Adjustment on DSAI 130
Channel adjustment consists of the following operations:
• Zero-point adjustment Z
• CMRR-balancing (Common Mode Rejection Ratio) B (= suppression of CMV).
Adjustment is normally not necessary except in exchange of components in this circuit.
• Full scale adjustment G.
Table 5-3. Adjustment Possibilities on Analog Circuit Boards
Type Channel adjustment Common adjustment Req. of DSFB 110
(1)
(1) If a potentiometer is not accessible from the front, place the board on an extension board DSFB 110.
DSAI 110 -- Z,G --
DSAI 130 Z, B, G Z, G, S
(2)
(2) Symmetry (S), which is adjusted in a test during manufacture, has the same effect as Gain (G),
but only on positive values.
Yes
DSAI 130A The module is calibrated at production
DSAI 133 -- G, Automatic adjustment
(3)
(3) DSAI 133 and DSAX 110 have automatically adjusted zero and automatically adjusted Gain caused by an onboard adjustable
voltage reference.
Yes
DSAI 133A The module is calibrated at production
DSAI 146 -- G --
DSAI 155A Automatic adjustment Automatic adjustment --
DSAX 110 -- G, Automatic adjustment
(3)
Yes
DSAO 110 Z, G, V, L1, L2 -- Yes
DSAO 120 Z, G -- --
DSAO 120A The module is calibrated at production
DSAO 130 G -- Yes
DSAO 130A The module is calibrated at production
DSAX 110A The module is calibrated at production
DSTY 101 Z, G -- --
