ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix I System Messages
I-14 3BSE 002 415R701 Rev A
15F 351 Event Set
167 359 S100 I/O bus extension (DSBC 174/DSBC 176)
16B 363 LONNV, LONWORKS Network Variables
16C 364 LONMNVI, LONWORKS Multiple Network Variables
16E 366 LON, LONWORKS Interface
Table I-12. Type 28
Type Code Data 1 Data 2 Comments/Actions
28 20 Concept,
instance No.
Bus fault. No board responds at the address used.
The board is extracted, faulty or incorrect jumpered.
H’011E
(286), x
H’xxxxyyyy Redundant S100 boards.
yyyy = 0 The unit (board 1 and board 2) has failed
yyyy = 1 Board 1 has failed
yyyy = 2 Board 2 has failed
H’015D
(349),x
H’xxxxyyyy MasterFieldBus
xxxx = Bus number
yyyy = Not used.
H’00B5
(181),x
H’xxxxyyyy MasterFieldBus nodes
xxxx = Bus number
yyyy = Node number
H’014D
(333),x
H’xxxxyyzz AF100 and PROFIBUS
xxxx=Bus number
yy=0: No redundant CI52x
yy=1: CI52x sub module 1
yy=2: CI52x sub module 2
zz = Station number (of CI52x or CI541)
H’014E
(334),x
H’xxxxyyyy AF100 stations and PROFIBUS slaves
xxxx = Bus number
yyyy = Station number
H’0145
(325),x
H’wwxxyyzz S800 I/O modules
ww = Bus number
xx = Station number
yy = Cluster number
zz = Position number
H’0167
(359),x
H’0000xxxx Single DSBC176 or redundant DSBC174 bus
extender
xxxx = 1 Left board has failed
xxxx = 2 Right board has failed.
Table I-11. List of Common Concept Numbers in System Messages
Hex Dec DB Element (Concerning)
