ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-15
28 21 Concept,
instance No.
The internal diagnostics of the board have reported
a hardware fault. There can also be a value too
small or too large on a reference channel.
H’011E
(286),x
H’xxxxyyyy Redundant S100 boards. Internal hardware status.
xxxx = H’0000 Undefined error.
xxxx = H’00C9 = Fault bit set.
xxxx = H’00CA = Toggle error.
xxxx = H’00CB = ADC reference error.
xxxx = H’00D2 = Checksum error.
xxxx = H’00D3 = Error in DPM.
xxxx = H’00D4 = Error in internal memory.
xxxx = H’00D5 = Error in external memory.
xxxx = H’00D6 = Watch dog error.
xxxx = H’00D7 = Interval clock error.
xxxx = H’00D8 = ADC reference error, 0 V.
xxxx =H’00D9 = ADC reference error, 10 V.
xxxx = H’00DA = ADC reference error, 5 V.
xxxx = H’00DB = Gain error.
xxxx = H’00DC = AO supervision error.
yyyy = 0 Board 1 and board 2 has failed.
yyyy = 1 Board 1 has failed
yyyy = 2 Board 2 has failed
H’015D
(349),x
H’xxxxyyyy MasterFieldBus
xxxx = Bus number
yyyy = Not used
H’00B5
(181),x
H’xxxxyyyy MasterFieldBus nodes
xxxx = Bus number
yyyy = Node number
Table I-12. Type 28 (Continued)
Type Code Data 1 Data 2 Comments/Actions
