ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix I System Messages
I-16 3BSE 002 415R701 Rev A
28 21 H’014D
(333),x
H’xxxxyyzz AF100 and PROFIBUS
xxxx = Bus number
yy = 0 No redundant CI52x
yy = 1 CI52x sub module 1
yy = 2 CI52x sub module 2
zz = Station number (of CI52x or CI541)
or
xxxxyyzz = 32-bit device error diagnostics.
H’014E
(334),x
H’xxxxyyyy AF100 stations and PROFIBUS slaves
xxxx = Bus number
yyyy = Station number
H’016E
(366),x
H’xxxxyyyy LON device error bits
xxxx = 0001 Error command
xxxx = 0002 EEPROM access error
xxxx = 0008 RAM Defective
xxxx = 0010 Parameter Checksum error
xxxx = 0030 Self test failed
xxxx = 0040 Watch dog time-out
xxxx = 0080 Runtime error
H’0145
(325),x
H’wwxxyyzz S800 I/O modules
ww = Bus number
xx = Station number
yy = Cluster number
zz = Position number
H’0167
(359),x
H’xxxxyyyy Single DSBC176 or redundant DSBC174 bus
extender
xxxx = Status from DSBC174 or DSBC176.
yyyy = 1 Left DSBC17x connected to left CPU.
yyyy = 2 Right DSBC174 connected to right CPU.
23 A measurement range not permitted for pulse
counter.
24 6,x An analog input has a value outside the working
range of the AD converter.
25 H’xxxxyyyy Interrupted communication on the distributed I/O
bus. See manual MasterFieldbus and S400 I/O
xxxx = Bus number
yyyy = Node number
26 H’xxxxyyyy Fault at one of the nodes of the distributed I/O bus.
xxxx = Bus number
yyyy = Node number
28 Channel fault in supervised AO channel.
Table I-12. Type 28 (Continued)
Type Code Data 1 Data 2 Comments/Actions
