ABB Advant Controller 450 - Mechanical Data

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ$ '66%( QHUJ\5HVHUYRLU
3BSE 002 415R701 Rev A A-9
7HFKQLFDO'DWD
0HFKDQLFDO'DWD
Width 482 mm (19”)
Height 177 mm (7”), 4 U
Depth 75 mm (3”)
Weight 2.8 kg (6.2 lbs.)
%ORFN'LDJUDP
7DEOH $ '66%2SHUDWLQJ'DWD
,WHP 9DOXH
Voltage rating input 24 V d.c.
Output voltage 24 V d.c.
Backup time
(in the range) 18.5 - 16 V with 25 A load
5 ms
Voltage derivative with power failure
with 25 A load
0.3 V/ms
'66%
X1 X2
1
2
3
4
1
2
3
4
