ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-54 3BSE 002 415R701 Rev A
 6,2
S100 I/O is the group of input and output boards located in the I/O subrack. The I/O subrack
communicates with the controller subrack using Bus Extension to S100 I/O. Single and
redundant Bus Extension to S100 I/O are available. Redundant S100 I/O Bus Extension requires
redundant processor module. Electrical and optical bus extensions are provided. See the outline
presentation of the bus extension in Section 1.7.7, Communication or to the separate
documentation mentioned.
Information in this section is divided according to the different categories of boards and
subdivided into 0 DLQ3RLQWV,available%RDUG7\SHVand a signal %ORFN'LDJUDP.
Regarding connection units and internal cables used in the hazardous and HART applications
you are referred to the separate documentation.
'LJLWDO,QSXW0DLQ3RLQWV
• All digital inputs are opto-isolated from the system potential.
Grouping of channels, with respect to isolation, can exist. See information given with the
actual board type and connection unit type.
• You can select the mode of data base updating, either by interrupts or by scanning.
The scan cycle times are normally selected from the range 10 ms to 2 s.
• Some boards offer pulse extension, for example to avoid rapid scanning of push buttons.
• The input signals are filtered on the input board to suppress the effects of electrical
interference or bouncing contacts. The filter time is fixed to 5 ms or configurable
depending on board type selected.
• Board types offering interrupt-controlled scanning are most suitable to get time-tagged
events.
'LJLWDO,QSXW%RDUG7\SHV
Table 1-13 presents available digital input boards.
7DEOH 'LJLWDO,QSXW%RDUGV
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
DSDI 110A 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
DSTD 150A / DSTD 190 DSTK 221L3
DSDI 110AV1 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
DSTD 150A / DSTD 190V1 DSTK 221L3
