ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ 3URFHVV,QWHUIDFH
3BSE 002 415R701 Rev A 1-55
DSDI 110A 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
Variants below provide
various rated input voltages,
all channels
galvanically isolated:
24 V d.c., 4 x DSTD 195
(1)
120 V a.c., 4 x DSTD 197
(1)
230 V a.c., 4 x DSTD 198
(1)
DSTK 226L3
DSTK 226L3
DSTK 226L3
DSDI 110AV1 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
Variants below provide
various rated input voltages,
all channels
galvanically isolated:
24 V d.c., 4 x DSTD 195
(2)
120 V a.c., 4 x DSTD 197
(2)
230 V a.c., 4 x DSTD 198
(2)
DSTK 226L3
DSTK 226L3
DSTK 226L3
DSDI 110A 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
24 V d.c. 4 x DSTD 196
(1)
This connection unit
provides 48 V d.c. over open
sensor contact.
DSTK 226L3
DSDI 110AV1 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt
24 V d.c. 4 x DSTD 196P
(2)
This connection unit
provides 48 V d.c. over open
sensor contact.
DSTK 226L3
DSDI 110A 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt.
Variants below provide object
oriented connection to
DSDI 110A and DSDO 115,
various rated input voltages:
24 V d.c. DSTD 145
120 V a.c. DSTD 147
230 V a.c. DSTD 148
DSTK 226L5
DSTK 226L5
DSTK 226L5
DSDI 110AV1 32 (4 x 8) channels, 24 V d.c., controlled by
scanning or interrupt.
Variants below provide object
oriented connection to
DSDI 110AV1 and
DSDO 115A, various rated
input voltages:
24 V d.c. DSTD 145
120 V a.c. DSTD 147
230 V a.c. DSTD 148
DSTK 226L5
DSTK 226L5
DSTK 226L5
7DEOH 'LJLWDO,QSXW%RDUGV&RQWLQXHG
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
