$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU &RQILJXUDWLRQ$SS OLFDWLRQ%XLOGLQJ
3-44 3BSE 002 415R701 Rev A
 7HFKQLFDO'DWD,QFOXGLQJ&DSDFLW\3HUIRUPDQFH
This section provides technical data that is relevant from a controller viewpoint. Much of the
detailed technical data about hardware modules is given in Appendix A, Hardware Modules.
This appendix gives a summary of the supported hardware modules. You can find references to
technical information either included in Appendix A or separately ordered.
Technical data about communication links is given in separate documentation for the specific
link.
The primary structure outlined in Section 1.8 Product Overview is the basis of the presentation.
The following subordinated headings are used when relevant:
• *HQHUDO7HFKQLFDO'DWD&DSDFLW\
Typical information given is maximum number of instances, magnitudes, distances, and so
on.
• 3HUIRUPDQFH
Typical information is accuracy, for example CPU load.
 *HQHUDO6\VWHP8WLOLWLHV
 &38
*HQHUDO7HFKQLFDO'DWD&DSDFLW\
3HUIRUPDQFH*HQHUDO
The load caused by different subsystems in the controller is reported below. To start with, you
will find an overview. The following headings cover details to respective subsystems, apart
from individual PC element load data, which is included in the PC element manual.
All performance data is based on actual measurements in Advant OCS configurations.
For instructions on how to make calculations, see Section 3.1.14, CPU-optimization, Load
Calculation.
127(
The performance of redundant processor modules is reduced to 95% in relation to
a single system. Divide all load figures given by 0.95.
7DEOH 7HFKQLFDO'DWDRI&38DQG0HPRU\
'DWD $GYDQW&RQWUROOHU
CPU type MC68040
Clock frequency 25 MHz
RAM (total) 8 alt. 16 MByte
RAM (for application) Calculate from Tabl e 3-9
