$GYDQW
&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ$ &,56 &&RPPXQLFDWLRQ,QWHUIDFH
3BSE 002 415R701 Rev A A-7
3RZHU6XSSO\
5 V typical 400 mA
max. 670 mA
24 V max. 40 mA
Power loss (heat) typical 3 W
0HFKDQLFDO'DWD
Module size: Occupying one submodule slot (H = 95 mm, L = 140 mm, connector not included)
Weight: 0.13 kg (0.29 lbs.)
7DEOH $ 3LQ'HVLJQDWLRQIRU&KDQQHODQG&RQQHFWRU;DQG;
3LQ 6KRUW 'HVFULSWLRQ
1 DCD Data Carrier Detect
2 RD Receive Data
3 TD Transmit Data
4 DTR Data Terminal Ready
5 GND Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 RI Ring Indicator
