ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ$ 6$[[3RZHU6 XSSO\8QLWV
3BSE 002 415R701 Rev A A-23
7HFKQLFDO'DWD
6DIHW\&ODVVLILFDWLRQ
Class I according to IEC 536 (earth protected).
3URWHFWLRQ5DWLQJ
IP20 according to IEC 529 (IEC 144).
,QVXODWLRQ
Rated insulation voltage 400 V a.c.
Dielectric test voltage 3250 V a.c., 50/60 Hz
7DEOH $ 6$[[,QGLYLGXDO7HFKQLFDO'DWD
3DUDPHWHU 6$ 6$ 6$ 6$ 6$ 6$
Mains voltage a.c., nominal 120 V 230 V 120 V 230 V 120 V 230 V
Mains voltage variation 85 - 110%
Mains voltage a.c., max. (f=47-65Hz) 142 V 285 V 142 V 285 V 142 V 285 V
Mains load VA 450 VA 900 VA 450 VA
Mains load W 320 W 705 W 320 W
cos φ 0.7 min. 0.75 min. 0.7 min.
Efficiency factor 85% typ.
Output voltage at max. current 26 V, 10 A 25 V, 25 A 50 V, 5 A
Ripple 100 Hz, peak to peak
r m s (at max. current)
2 V max. 1 V max. 4 V max.
0.7 V max. 0,35 V max. 1.4 V max.
Maximum load 10 A/260 W 25 A/600 W 5 A /260 W
d.c. voltage slope at mains blackout
and maximum current
200mV/ms 250 mV/ms 250 mV/ms
