1RWH: TN defined by standard EN 60 950. Install category II and III according to IEC 664.
7DEOH $ ,QGLYLGXDO7HFKQLFDO'DWD
3DUDPHWHU 69 69 69 69 6; 6; 6; 6; 6; 6;
Category
Supply main/aux aux aux aux aux main main aux main main main
Distributor expands.....
-- -- -- -- --
SX540
-- --
SX550
--
Expandable Y/N N N N N Y Y N Y Y N
Mains input Single Single Dual Dual Single Single Single Single Single Single
Mains
PRI
Type of network any any any any any any TN any any any
Install. category III III III III III III II III III III
Frequency , Hz 50 60 50 60 50/60 50/60 50/60 0 0 0
Rated insulation voltage, V 250 250 250 250 250 250 250 60 60 30
Dielectr. test voltage a.c., V 3250 3250 3250 3250 3250 3250 2200 1000 1000 1000
Rated input voltage, V 230 120 230 120 230/120 230/120 230/120 48 48 24
Rated input current, A 1.6 3.2 1.6 3.2 35 35 25 80 80 100
Primary fuse external, A ≤35 ≤35 ≤35 ≤35 ≤35 ≤35 ≤25 ≤80 ≤80 ≤100
Primary fuse internal, A Miniature Circuit Breaker, see Block Diag.
-- -- -- -- -- --
Outlet fuse, A
-- -- -- --
Miniature Circuit Breaker, see Block Diagram
SEC Type of network TN TN TN TN
-- -- -- -- -- --
Install. category II II II II
-- -- -- -- -- --
Rated insulation voltage, V 250 250 250 250
-- -- -- -- -- --
Dielectr. Test voltage a.c.,V 2200 2200 2200 2200
-- -- -- -- -- --
Rated output voltage, V 230 120 230 120
-- -- -- -- -- --
Rated output current, A
1.3 2.5 1.3 2.5
-- -- -- -- -- --
Outlet fuse Miniature Circuit Breaker, see Block Diagram
