$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-32 3BSE 002 415R701 Rev A
$GGLWLRQDO3&(OHPHQWV4&/,%
QC07-LIB42 extends the PC element library that is included in the basic system program
module with PC elements and functional units for supporting the functions listed below.
The optional program module QC7-LIB42 is selected for advanced controlling which requires
powerful operator’s functions from an Advant Station 500 Series Operator Station or a
MasterView 800/1.
Advanced process control requires, in addition to QC07-LIB42, the program module for
operator functions support, QC07-OPF41.
)XQFWLRQDO6XUYH\
• Feedback control
• Self-tuning adaptive control, NOVATUNE
• Functional units, PID loop control, PIDCON, PIDCONA.
Time
controlled
elements
Square- and sine-wave oscillators. OSC-SQW, OSC-SIN
Function gen-
erators
Generate an output from one or two input
variables according to a function described
by data tables or as a function of time.
FUNG-1V, FUNG-2V,
FUNG-T
Filter ele-
ments
Low-pass filters with one or two poles. FILT-1P, FILT-2P
Feedback
control ele-
ments
P, I and D functions and their combinations,
plus pulsed outputs and ramp generator.
P-DEADB, P-1, INT,
DER, PI, PIP, PDP,
CON-PU1, RAMP
Analog thyris-
tor converter
elements
Interface analog converters with PC
programs in Advant Controller 400 Series.
CVB-I, CVB-O
7DEOH $GGLWLRQDO3&(OHPHQWVLQ3URJUDP0RGXOH4&/,%&RQWLQXHG
7\SH )XQFWLRQ 3&HOHPHQW
