ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ 3URFHVV,QWHUIDFH
3BSE 002 415R701 Rev A 1-61
DSAI 155A 14 channels (+ two ref. channels + one comp. chan-
nel) for thermocouples, resolution
12/13 bits + sign, measurement range:
B, C, E, J, K, R, S and T for insulate
thermocouples
DSTA 156
DSTA 155
DSTK 225SL3
DSAI 155A 14 channels (+ two ref. channels + one comp. chan-
nel) for thermocouples, resolution
12/13 bits + sign, measurement range:
B, C, E, J, K, R, S and T for insulate
thermocouples
DSTA 156B
DSTA 155P
DSTK 225SL3
DSAX 110 $QDORJLQSXW
Eight channels, directly grounded inputs
(single ended) resolution 12 bits unipolar
0 to + 10 V or 0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
shunt 250 Ω 0.05%
$QDORJRXWSXW
Eight channels, resolution 12 bits unipolar
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
0 to + 10 V (over shunt 500 Ω 0.1% on
DSTA 001A)
DSTA 001A DSTK 223L3
DSAX 110A $QDORJLQSXW
Eight channels, directly grounded inputs
(single ended) resolution 12 bits unipolar
0 to + 10 V or 0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
shunt 250 Ω 0.05%
$QDORJRXWSXW
Eight channels, resolution 12 bits unipolar
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
0 to + 10 V (over shunt 500 Ω 0.1% on
DSTA 001B)
DSTA 001B DSTK 223L3
2 x DSAX 110 Redundant coupling. Data otherwise the same as for
DSAX 110 above.
DSTA 001A 2 x DSTK 223L3
2 x DSAX 110A Redundant coupling. Data otherwise the same as for
DSAX 110 above.
DSTA 001B 2 x DSTK 223L3
(1) Two connection units are used due to space requirement.
7DEOH $QDORJ,QSXW%RDUGV&RQWLQXHG
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
