ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-64 3BSE 002 415R701 Rev A
DSAX 110 $QDORJLQSXW
Eight channels, directly grounded inputs
(single ended) resolution 12 bits unipolar
0 to + 10 V,
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
shunt 250 Ω 0.05%
$QDORJRXWSXW
Eight channels, resolution 12 bits unipolar
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
0 to + 10 V (over shunt 500 Ω 0.1% on
DSTA 001)
DSTA 001A DSTK 223L3
DSAX 110A $QDORJLQSXW
Eight channels, directly grounded inputs
(single ended) resolution 12 bits unipolar
0 to + 10 V,
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
shunt 250 Ω 0.05%
$QDORJRXWSXW
Eight channels, resolution 12 bits unipolar
0 to + 20 mA,
4 to 20 mA (elevated zero obtained by SW)
0 to + 10 V (over shunt 500 Ω 0.1% on
DSTA 001)
DSTA 001B DSTK 223L3
2 x DSAX 110 Redundant coupling. Data otherwise the
same as for DSAX 110 above.
DSTA 001A 2 x DSTK 223L3
2 x DSAX 110 Redundant coupling. Data otherwise the
same as for DSAX 110 above.
DSTA 001B 2 x DSTK 223L3
7DEOH $QDORJ2XWS XW%RD UGV &RQWLQXHG
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
