ABB PFEA 112 - Assembly Drawing, 3 BSE015955 D0096, Rev. C

Tension Electronics PFEA111/112, User Manual
Appendix B PFCL 301E - Designing the Load Cell Installation
B-14 3BSE029380R0101 Rev C
B.12 Assembly Drawing, 3BSE015955D0096, Rev. C
Mass (approx. without cable) : 5 kg. Dimensions in : mm [inch]
REV DESCRIPTION DATE DEPT./INIT.
- New document 98-04-23 SEISY/AGM/GD
A
Thickness and width upper adapterplate was 11 respectively 76 mm.
2000-01-24 SEAPR/AGB/MH
B
Dimension 48 added. Toelerancs added to dimension 67, 77 178 and 228
2001-10-19 SEAPR/AGB/LEN
C
Redrawn in Solid Works and uppdated. Cable min bending radius added.
2013-02-25 PAMP/FMGF/LEN

 

 

 
 
 
 

 

 
 
C

 
 
ABB AB
2013-02-25
Cont.sh./ No of sh. SheetLang. Rev.
Project or order number : Modify date :
Document number
Appr. Prep. Resp.dept
Product type designation : Product information : Product family :
2013-02-25 10:13:18
PFCL 301E
661230 Bansp. mätare PRT100
ABB AB

 
Håkan F Wintzell

 
2013-02-25Lars-Erik Nilsson

 
1 1C
en
Assembly PFCL301E Assembly PFCL301E Dimension drawing
3BSE015955D0096
PA PA PA
FMGF FMGF FMGF
Document status:
Approved
Customer reference :
/ / /
33,5
1,32
67 ±0,5
2,64 ±0,02
2x 9,5
0,37
203
7,99
R 30 min
1,18
Cable length 8 m [315] OD 6,6 [0,26]
11
0,43
48 ±0,1
1,89 ±0,004
18
0,71
178 ±0,5
7,01 ±0,02
77 ±0,3
3,03 ±0,012
