Tension Electronics PFEA111/112, User Manual
Appendix A Technical Data for Tension Electronics PFEA111/112
A-4 3BSE029380R0101 Rev C
A.3 Technical Data
Table A-2. Data for Supply Voltage
Data Comments
Supply voltage
IP 20-unit (unsealed)
IP 65-unit (NEMA 4)
24 V DC
24 V DC
85 - 264 V AC
18 - 36 V DC
18 - 36 V DC
100 V -15% to 240 V +10%
Mains frequency 45 - 65 Hz 100 - 240 V AC, 0.2 - 0.1 A
Power
consumption
8 W (24 V)
Fuse
IP 20-unit (unsealed)
IP 65-unit (NEMA 4)
Automatic reset
Slow blow, 2 A, 250 V
Table A-3. Data for Load Cell Excitation
Data Comments
Current 0.5 A rms, 330 Hz Regulated
Max. load Two load cells + max. 5
cable resistance (1 F cable
capacitance).
Load cells of type:
PFCL 301E, PFTL 301E,
PFRL 101 and PFTL 101.
PFCL 201, PFTL 201.
Table A-4. Data for Load Cell Inputs
Data Comments
Number of inputs 2
Input impedance 10 kohm
