Tension Electronics PFEA111/112, User Manual
Section 2.1 About this Chapter
3BSE029380R0101 Rev C 2-1
Chapter 2 Installation
2.1 About this Chapter
The way you install your system has more influence on its functionality, accuracy and reliability
than you might think. The more accurate the installation, the better the measurement system. By
following the instructions in this chapter, you will fulfill the most important requirements for
proper mechanical and electrical installation.
The equipment is a precision instrument which, although intended for severe operating
conditions, must be handled with care.
2.2 Safety Instructions
Read and follow the safety instructions given in Chapter 1 , before starting any installation
work. However, local statutory regulations, if stricter, are to take precedence.
2.3 Mounting the Load Cells
Installation requirements and mounting instructions are given in:
• Appendix B PFCL 301E - Designing the Load Cell Installation
• Appendix C PFTL 301E - Designing the Load Cell Installation
• Appendix D PFRL 101 - Designing the Load Cell Installation
• Appendix E PFTL 101 - Designing the Load Cell Installation
• Appendix F PFCL 201 - Designing the Load Cell Installation
• Appendix G PFTL 201 - Designing the Load Cell Installation
