Tension Electronics PFEA111/112, User Manual
Chapter 3 Commissioning
3-12 3BSE029380R0101 Rev C
• N/m (Newton/meter)
• kN/m (kiloNewton/meter)
• kg/m (kilogram/meter)
• pli (pounds per linear inch)
If the selected unit is N/m, kN/m, kg/m or pli, the Web Width needs to be set.
Default Web Width is 2m (78,740 inch).
3.12.1.3 Set Web Width
The menu SetWebWidth will only be available when the selected unit is N/m, kN/m, kg/m or
pli.
Default Web Width is 2m (78,740 inch).
The format is XX.XXX if the width is entered in meter and XXXX.XX if the width is entered in
inch. Maximum Web Width is 50m (1968,5 inch)
3.12.1.4 Set Decimals
The number of displayed decimals can be set in this menu. The number of decimals may be set
to a number between 0 - 5 depending on the load cell nominal load and presentation unit.
Set decimals function is further explained in Section 4.6.
