Tension Electronics PFEA111/112, User Manual
Section 3.1 About this Chapter
3BSE029380R0101 Rev C 3-1
Chapter 3 Commissioning
3.1 About this Chapter
This chapter contains necessary information for commissioning your Web Tension System.
It is assumed that the Web Tension System has been installed according to the instructions given
in Chapter 2 Installation and Appendix (B, C, D, E, F or G) depending on installed load cell
type.
You must know the following data before starting commissioning:
1. Load cell type and nominal load, see Appendix for installed load cell type
2. Object type, see Section 3.12.2
– Standard roll (two load cells)
– Single side measurement (one load cell)
3. Maximum web tension
4. Desired output data at given web tension
5. Communication data, see Section 3.13
3.2 Safety Instructions
Read and follow the safety instructions stated in Chapter 1 Introduction, before starting any
commissioning work. However, local statutory regulations, if stricter, are to take precedence.
3.3 Necessary Equipment and Documentation
The following items are required:
• Cable diagram
• Service tools
