3.11 Performing a Complete Setup
3.11.1 Overview
The complete setup is built up by a number of main and sub menus. The table below shows the
main menus in order of appearance when stepping through the complete setup. The table also
gives an overview of the selections and parameter settings you can do below in each main menu.
The complete setup sequence is described in Section 3.12.
Main menus Selections and parameter settings
See details
in section...
Set language
Set unit/web width
Set Decimals
3.12.1
Set object type
- Standard roll (load cells A and B) or
- Single side measurement (load cell A or B)
3.12.2
Set nominal load 3.12.3
Zero set load cells 3.12.4
Set hanging weights (actual force) or
Set wrap gain (calculated value)
3.12.5
Set filter settings
Set high tension value and high output
voltage
Set low tension value and low output voltage
Set high and low output voltage limit
3.12.6
Set filter settings
Set high tension value and high output
current
Set low tension value and low output current
Set high and low output current limit
3.12.7
Set Profibus address and measuring range.
Reset all values to factory default
3.12.8
Read service information
Reset maximum load for load cell A
Reset maximum load for load cell B
Activate/deactivate simulation
3.12.9
