ABB PFEA 112 User Manual

Tension Electronics PFEA111/112, User Manual
Section D.9 Technical Data
3BSE029380R0101 Rev C D-13
D.9 Technical Data
Table D-2. Technical Data for Different Types of Load Cell PFRL 101
PFRL 101 Type Data Unit
Nominal load
Nominal load, F
nom
A 0.5 (112)
kN
(lbs)
B1 (225)
C 0.5 (112) 1 (225) 2 (450)
D 5 (1125)
Accepted transverse load within the
accuracy class, F
Vnom
A 2.5 (562)
B3 (674)
C 1.25 (281) 2.5 (562) 5 (1125)
D 10 (2250)
Accepted axial load within the
accuracy class, F
Anom
A 2.5 (562)
B 5 (1125)
C 2.5 (562) 5 (1125) 10 (2250)
D 25 (5625)
Overload capacity
Maximal load in the direction of
measurement without permanent
change of data, F
max
A 2.5 (562)
kN
(lbs)
B 5 (1125)
C 2.5 (562) 5 (1125) 10 (2250)
D 25 (5625)
Spring constant A 50 (286)
kN/mm
(1000
lbs/inch)
B 100 (572)
C 50 (286) 100 (572) 200 (1143)
D 500 (2858)
Mechanical data
Weight A 1.5 (3.3)
kg
(lbs)
B 2.0 (4.4)
C 5.0 (11) 5.0 (11) 5.0 (11)
D 8.5 (18.7)
