Tension Electronics PFEA111/112, User Manual
Section C.11 Dimension Drawing, 3BSE019040D0094, Rev. C
3BSE029380R0101 Rev C C-13
C.11 Dimension Drawing, 3BSE019040D0094, Rev. C
Mass: 2 kg (without cable). Dimensions :mm [inch]
REV DESCRIPTION DATE DEPT./INIT.
- New document 99-07-02 SEAPR/AGB/JRK
A The dimension 178 was removed from the top view 2000-02-22 SEAPR/AGB/MH B Tolerance added to dimension 48 and 178 2001-10-17 SEAPR/AGB/LEN
C
Redrawn in Solid Works, and updated. Mass added. Cable bending radius replace dim. 25 mm min.
2012-12-14 PA/FM/GF/LEN

 

 

 
 
 
 

 

 
 
C

 
 
ABB AB
2012-12-14
Cont.sh./ No of sh. SheetLang. Rev.
Project or order number : Modify date :
Document number
Appr. Prep. Resp.dept
Product type designation : Product information : Product family :
2012-12-13 10:22:49
PFTL 301E
661230 Bansp. mätare PRT100
ABB AB

 
Håkan F Wintzell

 
2012-12-14Lars-Erik Nilsson

 
1 1C
en
Lastcell PFTL301E Load Cell PFTL301E Dimension drawing
3BSE019040D0094
PA PA PA
FM/GF FM/GF FM/GF
Document status:
Approved
Customer reference :
/ / /
178 ±0,15
7,01 ±0,006
48 ±0,1
1,89 ±0,004
46
1,81
49
1,93
58,2
2,29
110
4,33
34
1,34
32
1,26
8,5
0,33
R30 min
8x M8
52
2,05
