ABB PFEA 112 - Measuring Values on the Display

Tension Electronics PFEA111/112, User Manual
Section 4.6 Measuring values on the display
3BSE029380R0101 Rev C 4-3
4.6 Measuring values on the display
Depending on the selected unit, the measuring values will be presented differently, see
Table 4-1 and Table 4-2.
Table 4-1. Measuring values presented on the display.
Table 4-2. Measuring values presented on the display.
X in Table 4-1 and Table 4-2 indicates that the figure is changed if the value is changed.
0 indicates that the value is not changed if the value changes.
Load cell
nominal load
[N] [kN] [kg] [lbs]
0.1 [kN] XX XXX.X XX.XXXX X XXX.XX X XXX.XX
0.2 [kN] XX XXX.X XX.XXXX X XXX.XX X XXX.XX
0.5 [kN] XX XXX.X XX.XXXX X XXX.XX X XXX.XX
1 [kN] XXX XXX XXX.XXX XX XXX.X XX XXX.X
2 [kN] XXX XXX XXX.XXX XX XXX.X XX XXX.X
5 [kN] XXX XXX XXX.XXX XX XXX.X XX XXX.X
10 [kN] X XXX XX0 X XXX.XX XXX XXX XXX XXX
20 [kN] X XXX XX0 X XXX.XX XXX XXX XXX XXX
50 [kN] X XXX XX0 X XXX.XX XXX XXX XXX XXX
100 [kN] X XXX X00 X XXX.X XXX XX0 X XXX XX0
200 [kN] X XXX X00 X XXX.X XXX XX0 X XXX XX0
Load cell
nominal load
[N/m] [kN/m] [kg/m] [pli]
0.1 [kN] XX XXX.XX XX.XXXXX X XXX.XXX X XXX.XXXX
0.2 [kN] XX XXX.XX XX.XXXXX X XXX.XXX X XXX.XXXX
0.5 [kN] XX XXX.XX XX.XXXXX X XXX.XXX X XXX.XXXX
1 [kN] XXX XXX.X XXX.XXXX XX XXX.XX XX XXX.XXX
2 [kN] XXX XXX.X XXX.XXXX XX XXX.XX XX XXX.XXX
5 [kN] XXX XXX.X XXX.XXXX XX XXX.XX XX XXX.XXX
10 [kN] X XXX XXX X XXX.XXX XXX XXX.X XXX XXX.XX
20 [kN] X XXX XXX X XXX.XXX XXX XXX.X XXX XXX.XX
50 [kN] X XXX XXX X XXX.XXX XXX XXX.X XXX XXX.XX
100 [kN] X XXX XX0 X XXX.XX XXX XXX XXX XXX.X
200 [kN] X XXX XX0 X XXX.XX XXX XXX XXX XXX.X
