Tension Electronics PFEA111/112, User Manual
Chapter 3 Commissioning
3-14 3BSE029380R0101 Rev C
3.12.3 Nominal Load
Figure 3-8. Nominal Load Menus
The nominal load is selected from the list below and must be the same as the nominal load on
the load cell name plate. The load cell nominal load is displayed in kN and lbs on the same row.
The following nominal loads can be selected:
Table 3-2. Nominal Loads
[kN] [lbs]
0.1 22
0.2 45
0.5 112
1.0 225
2.0 450
5.0 1125
10 2250
20 4500
50 11250
100 22500
200 45000
SetObject
FastSetUp
WebTension
Presentation-
Menu
NominalLoad
ServiceMenu
ZeroSet
SetWrapGain
> 5 s
CurrentOutput
VoltageOutput
Miscellaneous
Menu
NominalLoad
ZZ kN ZZ lbs
NominalLoad
[ZZ kN ZZ lbs]
From SetObject
To ZeroSet
To Next Page
