Tension Electronics PFEA111/112, User Manual
Section A.3 Technical Data
3BSE029380R0101 Rev C A-5
Table A-5. Data for Signal Outputs
Data Comments
Voltage output 0 - 10 V Range -5 to +11 V
Max. load 5 mA
Ripple <10 mV
p-p
Wrap gain = 1
Step response time 15 ms
Band width 35 Hz
Current output 4 - 20 mA Range 0 to 21 mA
Max. load 550
Step response time 15 ms
Band width 35 Hz
Extra filtering for
voltage and current
output
Filter setting
Cut-off frequency
30 ms 75 ms 250 ms 750 ms 1500 ms
15 Hz 5 Hz 1.5 Hz
0.5 Hz 0.25 Hz
Wrap gain
adjustment
0.5 - 20
Table A-6. Measurement Ranges for the Tension Electronics
Type Range
(1)
(1) F
nom
= Load cell nominal load
Zero Setting Range ±2.0 F
nom
Dynamic Measurement Range
(including zero set)
–2.5 F
nom
to + 3.5 F
nom
Table A-7. Communication PFEA112
Data Comments
Profibus 112 Mbit
Communication
protocol
Profibus DP slave According to EN 50 170
Transfer speed Max. 12 Mbits / s
Address range 0 - 125
