6.5.4 Signals
Table 49: SDEPSDE (67N) Input signals
Name
Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
U3P GROUP
SIGNAL
- Three phase group signal for voltage inputs
BLOCK BOOLEAN 0 Block of function
BLKUN BOOLEAN 0 Blocks the non-directional voltage residual outputs
Table 50: SDEPSDE (67N) Output signals
Name Type Description
TRIP BOOLEAN Common trip signal
TRDIRIN BOOLEAN Trip of the directional residual overcurrent
TRNDIN BOOLEAN Trip of non-directional residual overcurrent
TRUN BOOLEAN Trip of non-directional residual overvoltage
START BOOLEAN General pickup signal
STDIRIN BOOLEAN Pick up of the directional residual overcurrent function
STNDIN BOOLEAN Pick up of non directional residual overcurrent
STUN BOOLEAN Pick up of non directional residual overvoltage
STFW BOOLEAN Pick up of directional function for fault in forward
direction
STRV BOOLEAN Pick up of directional function for fault in reverse
direction
STDIR INTEGER Direction of fault
UNREL BOOLEAN Residual voltage release of operation of directional
modes
6.5.5 Settings
Table 51: SDEPSDE (67N) Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Disable / Enable
OpMode 3I0Cosfi
3I03V0Cosfi
3I0 and fi
-
- 3I0Cosfi Selection of operation mode for protection
DirMode Forward
Reverse
- - Forward Direction of operation forward or reverse
Table continues on next page
1MRK 511 287-UUS A Section 6
Current protection
117
Technical manual
