ABB REC650 ANSI - Basic IED Functions

IEC 61850 or Function
name
ANSI Function description Bay
REC650
REC650 (A01A)
3Ph/1CBA
REC650 (A02A)
3Ph/1CBAB
REC650 (A07A)
BCAB
CONFPROT IED Configuration Protocol 1 1 1 1
ACTIVLOG Activity logging parameters 1 1 1 1
SECALARM Component for mapping security events on
protocols such as DNP3 and IEC103
1 1 1 1
AGSAL Generic security application component 1 1 1 1
GOOSEDPRCV GOOSE function block to receive a double point
value
32 32 32 32
GOOSEINTRCV GOOSE function block to receive an integer
value
32 32 32 32
GOOSEMVRCV GOOSE function block to receive a measurand
value
16 16 16 16
GOOSESPRCV GOOSE function block to receive a single point
value
64 64 64 64
2.4 Basic IED functions
IEC 61850/Function
block name
Function description
Basic functions included in all products
INTERRSIG Self supervision with internal event list 1
SELFSUPEVLST Self supervision with internal event list 1
TIMESYNCHGEN Time synchronization 1
SNTP Time synchronization 1
DTSBEGIN, DTSEND,
TIMEZONE
Time synchronization, daylight saving 1
IRIG-B Time synchronization 1
SETGRPS Setting group handling 1
ACTVGRP Parameter setting groups 1
TESTMODE Test mode functionality 1
CHNGLCK Change lock function 1
PRIMVAL Primary system values 1
SMAI_20_1 -
SMAI_20_12
Signal matrix for analog inputs 2
3PHSUM Summation block 3 phase 12
Table continues on next page
1MRK 511 287-UUS A Section 2
Available functions
43
Technical manual
