15.3.2 Setting group handling SETGRPS
15.3.2.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Setting group handling SETGRPS - -
15.3.2.2 Settings
Table 498: SETGRPS Non group settings (basic)
Name Values (Range) Unit Step Default Description
ActiveSetGrp SettingGroup1
SettingGroup2
SettingGroup3
SettingGroup4
-
- SettingGroup1 ActiveSettingGroup
MaxNoSetGrp 1 - 4 - 1 1 Max number of setting groups 1-4
15.3.3 Parameter setting groups ACTVGRP
15.3.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Parameter setting groups ACTVGRP - -
15.3.3.2 Function block
ANSI09000064-1-en.vsd
ACTVGRP
ACTGRP1
ACTGRP2
ACTGRP3
ACTGRP4
GRP1
GRP2
GRP3
GRP4
GRP_CHGD
ANSI09000064 V1 EN
Figure 268: ACTVGRP function block
