Name Type Description
VP289TR BOOLEAN Switch status of 289 is valid (open or closed)
VP789TR BOOLEAN Switch status of 789 is valid (open or closed)
VP1289TR BOOLEAN Switch status of 189 and 289 are valid (open or closed)
10.4.9.6 Settings
The function does not have any settings available in Local HMI or Protection and Control
IED Manager (PCM600).
10.4.10 Interlocking for transformer bay AB_TRAFO (3)
10.4.10.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Interlocking for transformer bay AB_TRAFO - 3
10.4.10.2 Functionality
The interlocking for transformer bay (AB_TRAFO, 3) function is used for a transformer
bay connected to a double busbar arrangement according to figure 149. The function is
used when there is no disconnector between circuit breaker and transformer. Otherwise,
the interlocking for line bay (ABC_LINE, 3) function can be used. This function can also
be used in single busbar arrangements.
