10.3.7.3 Function block
IEC09000074_1_en.vsd
LOCREMCTRL
^PSTO1
^PSTO2
^PSTO3
^PSTO4
^PSTO5
^PSTO6
^PSTO7
^PSTO8
^PSTO9
^PSTO10
^PSTO11
^PSTO12
^HMICTR1
^HMICTR2
^HMICTR3
^HMICTR4
^HMICTR5
^HMICTR6
^HMICTR7
^HMICTR8
^HMICTR9
^HMICTR10
^HMICTR11
^HMICTR12
IEC09000074 V1 EN
Figure 114: LOCREMCTRL function block
10.3.7.4 Signals
Table 191: LOCREMCTRL Input signals
Name
Type Default Description
PSTO1 INTEGER 0 PSTO input channel 1
PSTO2 INTEGER 0 PSTO input channel 2
PSTO3 INTEGER 0 PSTO input channel 3
PSTO4 INTEGER 0 PSTO input channel 4
PSTO5 INTEGER 0 PSTO input channel 5
PSTO6 INTEGER 0 PSTO input channel 6
PSTO7 INTEGER 0 PSTO input channel 7
PSTO8 INTEGER 0 PSTO input channel 8
PSTO9 INTEGER 0 PSTO input channel 9
PSTO10 INTEGER 0 PSTO input channel 10
PSTO11 INTEGER 0 PSTO input channel 11
PSTO12 INTEGER 0 PSTO input channel 12
