Table 13: Ethernet front port settings
Parameter Values (Range) Unit Step Default Description
IP address 192.168.0.254 IP address for front port (fixed)
Mac address XX-XX-XX-XX-
XX-XX
Mac address for front port
Table 14: Ethernet rear port settings
Parameter Values (Range) Unit Step Default Description
IP address 192.168.2.10 IP address for rear port(s)
Subnet mask 255.255.255.0 Subnet mask for rear port(s)
Default gateway 192.168.2.1 Default gateway for rear port(s)
Mac address XX-XX-XX-XX-
XX-XX
Mac address for rear port(s)
Table 15: Redundancy settings
Parameter Values (Range) Unit Step Default Description
Switch mode Normal
HSR
PRP
Normal Mode selection for Ethernet switch on
Redundant communication modules
Table 16: DIAGLCCH1 Output signals
Name
Values Description
CHLIV True
False
Status of LAN A in HSR mode
REDCHLIV True
False
Status of LAN B in HSR mode
Table 17: XGGIO90 Output signals
Name
Values Description
ETHLNK1 Up
Down
Status of Ethernet link 1
ETHLNK2 Up
Down
Status of Ethernet link 2
ETHLNK3 Up
Down
Status of Ethernet link 3
1YHT530004D05 D Section 3
Basic functions
615 series 47
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
