Module ID RJ-45 LC EIA-485 EIA-232 ST
COM0032 1 2 - - 1
COM0033 3 - - - 1
COM0034 2 1 - - 1
1) Available only for RED615.
Table 666: LED descriptions for COM0001-COM0014
LED Connector
Description
1)
X1 X1 X1/LAN link status and activity (RJ-45 and LC)
RX1 X5 COM2 2-wire/4-wire receive activity
TX1 X5 COM2 2-wire/4-wire transmit activity
RX2 X5 COM1 2-wire receive activity
TX2 X5 COM1 2-wire transmit activity
I-B X5 IRIG-B signal activity
1) Depending on the COM module and jumper configuration
Table 667: LED descriptions for COM0008 and COM0010
LED
Connector
Description
1)
X16 X16 X16/LD link status and activity
X1 X1 X1/LAN link status and activity
X2 X2 X2/LAN link status and activity
RX X5 COM1 2-wire receive activity/COM2 4-wire receive activity
TX X5 COM1 2-wire transmit activity/COM2 4-wire transmit activity
RX X5/X12 COM2 2-wire receive activity/COM2 4-wire receive activity
TX X5/X12 COM2 2-wire transmit activity/COM2 4-wire transmit activity
I-B X5 IRIG-B signal activity
1) Depending on the jumper configuration
Table 668: LED descriptions for COM0023
LED
Connector
Description
1)
FX X12 Not used by COM0023
X1 X1 LAN Link status and activity (RJ-45 and LC)
FL X12 Not used by COM0023
RX X6 COM1 2-wire / 4-wire receive activity
TX X6 COM1 2-wire / 4-wire transmit activity
RX X5 / X12 COM2 2-wire / 4-wire or fiber-optic receive activity
TX X5 / X12 COM2 2-wire / 4-wire or fiber-optic transmit activity
I-B X5 IRIG-B signal activity
1) Depending on the jumper configuration
Section 13 1YHT530004D05 D
IED physical connections
854 615 series
Technical Manual
