6243/44 DC Voltage Current Source/Monitor Operation Manual
6.4.2 Data Output Format in the TR6143 Mode (Talker)
6-15
• Fixed-point part and exponent part
The fixed-point part and exponent part are determined by the source/measurement function, range
and number of measurement digits.
• String delimiter
A string delimiter is output to set off sets of data.
The string delimiter can be specified by commands.
Measurement
function
Range
Fixed-point
Exponent
value
5 1/2-digit
measurement
(eight characters)
4 1/2-digit measurement
(seven characters)
Voltage
320 mV ddd.ddd ddd.dd E - 3
3.2 V d.ddddd d.dddd E + 0
32 V/20 V dd.dddd dd.ddd E + 0
110 V ddd.ddd ddd.dd E + 0
Current
32 A dd.dddd dd.ddd E - 6
320 A ddd.ddd ddd.dd E - 6
3.2 mA d.ddddd d.dddd E - 3
32 mA dd.dddd dd.ddd E - 3
320 mA ddd.ddd ddd.dd E - 3
2 A/3.2 A d.ddddd d.dddd E + 0
10 A dd.dddd dd.ddd E + 0
Over range +999.999 +999.99 E + 9
String delimiter Setting command Default
“,” Comma SL0
“ ” Space SL1
CR LF SL2
To Next Page
